Input voltage range |
90Vac to 260Vac |
Normal voltage range 標(biāo)稱輸入 |
4.2V-40A |
Frequency range 頻率范圍 |
47Hz—63Hz |
Voltage adjustment range 電壓可調(diào)節(jié)范圍 |
3.8V~4.2V 可調(diào) |
Max input ac current 最大輸入電流 |
3.5Amax. at full load condition |
Inrush current (cold state) 浪涌電流 |
80A@220V |
Efficiency (full load) 效率 |
88%min.@230Vac |
Leakage Current 泄漏電流 |
Less Than 3.5mA, @ 230Vac input |
Normal output power 額定功率 |
168W |
Input Fuse 輸入保險 |
T5AH/250Vac |
Power Factor 功率因素 |
PF>0.9/230Vac |
Safety Certification |
CE |
