Input voltage range |
200Vac to 240Vac |
|
200Vac to 240Vac |
V1: 4.5V--45A |
|
V2: 3.6V--35A |
||
Frequency range 頻率范圍 |
47Hz—63Hz |
|
Voltage adjustment range 電壓可調(diào)節(jié)范圍 |
V1: 4.5V |
|
V2: 3.6V |
||
Max input ac current 最大輸入電流 |
4.9Amax. at full load condition |
|
Inrush current (cold state) 浪涌電流 |
80A@220V |
|
Efficiency (full load) 效率 |
||
Leakage Current 泄漏電流 |
Less Than 1.0mA, @ 220Vac input |
|
Normal output power 額定功率 |
328.5W Max |
|
Input Fuse 輸入保險(xiǎn) |
T6.3AL/250Vac |
|
Power Factor 功率因素 |
PF>0.9/230Vac |
|
Safety Certification |
符合CE ,3C |
