Input voltage range |
100Vac to 264Vac |
Normal voltage range 標稱輸入 |
100Vac to 200Vac 5V--60A 200Vac to 240Vac 5V--100A |
Frequency range 頻率范圍 |
47Hz—63Hz |
Max input ac current 最大輸入電流 |
5.9Amax. at full load condition |
Inrush current (cold state) 浪涌電流 |
100A@220V |
Efficiency (full load) 效率 |
91%min.@230Vac |
Leakage Current 泄漏電流 |
Less Than 1.0 mA, @ 230Vac input |
Normal output power 額定功率 |
500W |
Input Fuse 輸入保險 |
T6.3AH/250Vac |
Power Factor 功率因素 |
PF>0.95/220Vac |
Safety Certification(安規認證) |
3C CE |
