Input voltage range |
100Vac to 264Vac |
Normal voltage range 標(biāo)稱輸入 |
100Vac to 200Vac 5V--100A 200Vac to 240Vac 5V--120A |
Frequency range 頻率范圍 |
47Hz—63Hz |
Max input ac current 最大輸入電流 |
6.9Amax. at full load condition |
Inrush current (cold state) 浪涌電流 |
100A@220V |
Efficiency (full load) 效率 |
|
Leakage Current 泄漏電流 |
Less Than 1.0 mA, @ 220Vac input |
Normal output power 額定功率 |
600W@230VAC |
Input Fuse 輸入保險 |
T8AH/250Vac |
Power Factor 功率因素 |
PF>0.95/220Vac |
Safety Certification(安規(guī)認(rèn)證) |
